Built Tetris Using ReactJS
Problem
I wanted to learn a new UI framework. In the past, I’ve gone through Angular. Now it’s time to devour ReactJS. Maybe the next logical step is to learn React Ionic and/or React Native?
Solution
I’ve spent the past 2 working days going through the ReactJS tutorials here.
Next, I’ve decided to build a Tetris game using ReactJS. However, I’ve ended up using a bunch more plain JavaScript lol.
How I Built it
First, I needed a step counter to move the active piece down automatically. This is straightforward with JavaScript’s builtin setInterval function. However, this may collide with user input when the down key is pressed once. There can be a times when a single down key is pressed and the auto setInterval down activates at the same time which renders two downs at the same time. This is not ideal. Thus, modifying the code, so that whenever, down key is pressed, the auto setInterval is destroyed and then re-initialized whenever the down key is lifted. This allows the auto setInterval to be restarted.
function stepCounter() {
// auto move active pieve down
}
let intervalId_gameEngineStepCounter = 0;
function gameEngineStepCounter_Start(stepCounter) {
if (intervalId_gameEngineStepCounter === 0) {
intervalId_gameEngineStepCounter = setInterval(stepCounter, 1000);
}
}
function gameEngineStepCounter_Stop() {
if (intervalId_gameEngineStepCounter !== 0) {
clearInterval(intervalId_gameEngineStepCounter);
intervalId_gameEngineStepCounter = 0;
}
}
function keydownEC(event) {
if (event.key === "ArrowDown") {
gameEngineStepCounter_Stop();
// do manual down move
}
}
function keyupEC(event) {
if (event.key === "ArrowDown") {
gameEngineStepCounter_Start(stepCounter);
}
}
Next, I needed to figure out how to visually display the grid. I’ve opted for canvas as it was easier to manipulate. Since each grid square is 40px by 40px, so the canvas size will be 400px by 800px. I’ve added an additional 4px on each side for padding/borders.
<canvas className="canvas" width="404" height="804" ref={canvasRef} />
Next, I needed to figure out how to manage the game state. I’ve opted for a 2D array of numbers all initialized to 0. This will denote empty
gridState = Array.from({ length: 20 }, () => new Array(10).fill(0));
Originally it was
gridState = Array.from({ length: 10 }, () => new Array(20).fill(0));
But this was harder to manipulate the clearing of lines function.
Next, I needed to figure out how to manage the pieces. I’ve opted for a 2D array for each tetris piece. And the number will denote the color for the rendering function.
const pieceMap = [
[[0,0,0,0],
[0,1,1,0],
[0,1,1,0],
[0,0,0,0]],
[[0,2,0,0],
[0,2,0,0],
[0,2,0,0],
[0,2,0,0]],
[[0,3,0],
[0,3,3],
[0,3,0]],
[[0,4,0],
[0,4,4],
[0,0,4]],
[[0,0,5],
[0,5,5],
[0,5,0]],
[[0,0,0,0,0],
[0,0,0,0,0],
[0,0,6,6,0],
[0,0,6,0,0],
[0,0,6,0,0]],
[[0,0,7,0,0],
[0,0,7,0,0],
[0,0,7,7,0],
[0,0,0,0,0],
[0,0,0,0,0]],
];
Next, I needed to figure out the move logic for the active piece: left, right, rotate, and hard drop. How do you encode collision detection? Well, it can be easily done by simulating a move ahead of time and if there are any overlaps, collisions, or out of bounds.
Simulating move right
isCollision(gridState, curPieceX + 1, curPieceY, curPieceMap)
Simulating move left
isCollision(gridState, curPieceX - 1, curPieceY, curPieceMap)
Simulating move down
isCollision(gridState, curPieceX, curPieceY + 1, curPieceMap)
Collision logic
function isCollision(gridState, curPieceX, curPieceY, curPieceMap) {
let xSize = curPieceMap.length;
let ySize = curPieceMap[0].length;
for (let i = 0; i < xSize; i++) {
for (let j = 0; j < ySize; j++) {
let x = curPieceX + i;
let y = curPieceY + j;
if (curPieceMap[i][j] !== 0) {
if (y > 19 || x < 0 || x > 9) { // check for out of bounds
return true;
} else {
if (y < 0) { // if above the grid that's fine
// do nothing
} else if (gridState[y][x] !== 0) {
return true;
}
}
}
}
}
return false;
}
Next, is making it pretty. I’ve googled some images of tetris blocks that would be simple for canvas rendering.
function renderBlock(ctx, x, y, gridStateValue, x_shift = 0, y_shift = 0) {
let fillColor = 'blue';
let fillColorShade = 'blue';
// Fill Color
ctx.fillStyle = fillColor;
ctx.fillRect((x * 40) + 2 + x_shift, (y * 40) + 2 + y_shift, 40, 40); // x, y, width, height
ctx.fill();
// Fill Color Shade
ctx.fillStyle = fillColorShade;
ctx.fillRect((x * 40) + 2 + x_shift, (y * 40) + 2 + y_shift, 15, 40); // x, y, width, height
ctx.fill();
ctx.fillStyle = fillColorShade;
ctx.fillRect((x * 40) + 2 + x_shift, (y * 40) + 2 + 25 + y_shift, 40, 15); // x, y, width, height
ctx.fill();
// Outline
ctx.strokeStyle = 'rgb(41,39,39)'; // Set the stroke color
ctx.lineWidth = 4; // Set the line width
ctx.strokeRect((x * 40) + 2 + x_shift, (y * 40) + 2 + y_shift, 40, 40); // Draw an outlined red rectangle
}
Next, we need to color map based on the piece value
switch (gridStateValue) {
case 1:
// Code to execute if expression === value1
fillColor = 'rgb(251,219,15)';
fillColorShade = 'rgb(255,193,0)';
break;
case 2:
fillColor = 'rgb(0,247,255)';
fillColorShade = 'rgb(2,195,212)';
break;
case 3:
fillColor = 'rgb(137,59,253)';
fillColorShade = 'rgb(114,18,254)';
break;
case 4:
fillColor = 'rgb(254,103,2)';
fillColorShade = 'rgb(254,5,0)';
break;
case 5:
fillColor = 'rgb(0,180,0)';
fillColorShade = 'rgb(0,164,1)';
break;
case 6:
fillColor = 'rgb(252,110,1)';
fillColorShade = 'rgb(216,100,0)';
break;
case 7:
fillColor = 'rgb(1,0,252)';
fillColorShade = 'rgb(1,0,194)';
break;
default:
// Code to execute if no case matches
}
And that’s pretty much it… the rest is just fleshing out the game logic.
